The PE pipe production line uses our company's dedicated high-efficiency extruder for HDPE and PP pipes. The screw adopts a barrier and mixing head structure, and the barrel adopts a new type of slotted barrel. The plasticizing and mixing effects are good, and the extrusion volume is large and very stable,
- introduction
- Technical parameters
- Inquiry now
- Related products
Advantages of HDPE Pipe Extrusion Line:
HDPE pressure Pipe Extrusion Line is a pipe extrusion line developed byHSD company through assimilate and master technology introduced fromabroad. lt is applicable for extrusion of PE, PP, PB, PERT, ABS etc. ThisPE pipe production line can instead extrusion line imported from abroad.This pipe extrusion line mainly includes single screw extruder, molds,vacuum calibrating water tank, spray water cooling tank, haul-off machine,cutting machine and bracket.Plastic Pipes produced by this line have excellent stiffness, flexibility, highmechanical strength, resistance of environmental stress cracks, resistanceto creep defommation, heat-inkage and so on. lt has become the firstchoice for the city gas pipe, water supply pipe, foundation pipe, landfillcollection pipe, watermain, geothermal heating etc.
| style | SPEG-110 | SPEG-160 | SPEG-250 | SPEG-450 | SPEG-630 | SPEG-1200 | SPEG-2000 |
| MM | Φ20-Φ110 | Φ50-Φ160 | Φ63-Φ250 | Φ110-Φ450 | Φ315-Φ630 | Φ710-Φ1200 | Φ1200-Φ2000 |
| KG/H | 250 | 300 | 350 | 600 | 1000 | 1400 | 2000 |
| （kw ） | 180 | 200 | 210 | 298 | 522 | 680 | 1380 |
